Standard Unidirectional Thyrist

Type	Datasheet	Circuit	Marking	IT(RMS)	ITSM@50Hz	VDRM	VRRM	IGT(1-3)	TJ	Package
Type	Datasheet	Circuit	Marking	A	A	V	V	mA	℃	Package
Reset All	/	/	/	Reset OK	Reset OK	Reset OK	Reset OK	Reset OK	Reset OK	TO-126 TO-220AB TO-220B TO-247 TO-252 TO-3P Reset
	/	/	/
BT152-600				20	200	600	600	30	125	TO-220AB
BT152-800				20	200	800	800	30	125	TO-220AB
2P4MD-600				2	20	600	600	0.2	110	TO-252
2P4MD-800				2	20	800	800	0.2	110	TO-252
X0405D-600				4	30	600	600	0.2	110	TO-252
X0405D-800				4	30	800	800	0.2	110	TO-252
2P4MC			YFW 2P4MC	2	20	600	600	0.2	110	TO-126
BCB80A	/	/	YFW BCB80A	80	900	1200	1200	60	125	TO-247
BT151-600				12	120	600	600	15	125	TO-220B
BT151-800				12	120	800	800	15	125	TO-220B
BT151-1000				12	120	1000	1000	15	125	TO-220B
TYN840				40	460	800	800	35	125	TO-220B
TYN1040				40	460	1000	1000	35	125	TO-220B
TYN1240				40	460	1200	1200	35	125	TO-220B
BT151D-600				12	95	600	600	10	125	TO-252
BT151D-800			YFW BT151D 800	12	95	800	800	10	125	TO-252
BT152D-800				20	200	800	800	10	125	TO-252
BT152D-600			YFW BT152D-600	20	200	600	600	10	125	TO-252
FS4040-12M				40	380	1200	1200	35	125	TO-3P
FS4040-16M				40	380	1600	1600	35	125	TO-3P
BCB60			YFW BCB60	60	600	1600	1600	60	125	TO-247
X0405C-6			YFW X0405C 6	4	30	600	600	0.2	110	TO-126
X0405C-8			YFW X0405C 8	4	30	800	800	0.2	110	TO-126
