1. Current Gain (hFE or β)

The current gain, denoted as hFE (hybrid parameter) or β (beta), is a fundamental parameter that quantifies the transistor’s ability to amplify current. It represents the ratio of the collector current (I<sub>C</sub>) to the base current (I<sub>B</sub>) in bipolar junction transistors (BJTs) or the drain current (I<sub>D</sub>) to the gate-source voltage (V<sub>GS</sub>) in MOSFETs. For example, a transistor with hFE = 100 can amplify a 10 mA base current to 1 A at the collector.


YFW’s transistors, such as the 2SA1013-Y PNP BJT , feature a current gain of 60 at 200 mA, making them suitable for applications requiring moderate amplification. Higher hFE values are ideal for low-power amplifiers, while lower values are preferred in high-power switching circuits to minimize base current requirements.

2. Collector-Emitter Voltage (V<sub>CEO</sub>)

The maximum voltage that can be sustained between the collector and emitter terminals without breakdown is critical for circuit safety. Exceeding V<sub>CEO</sub> can lead to irreversible damage. YFW’s 2SC2383-Y NPN BJT , for instance, is rated at 160 V, ensuring robust operation in high-voltage environments like industrial power supplies.


Designers must consider V<sub>CEO</sub> when selecting transistors for applications such as motor drivers or voltage regulators, where transient voltages may occur. YFW’s adherence to JEDEC standards ensures that their transistors meet international safety and performance benchmarks.

3. Collector Current (I<sub>C</sub>) and Power Dissipation (P<sub>D</sub>)

The maximum continuous collector current (I<sub>C</sub>) and power dissipation (P<sub>D</sub>) determine the transistor’s handling capacity. P<sub>D</sub> is calculated as V<sub>CE</sub> × I<sub>C</sub> and is influenced by thermal design. YFW’s 2SA1013-Y supports a collector current of 1 A and a power dissipation of 500 mW , making it suitable for applications like audio amplifiers or LED drivers.


For high-power applications, YFW offers transistors with enhanced thermal management, such as those in TO-220 packages, which efficiently dissipate heat. Proper heat sinking is essential to prevent thermal runaway and ensure long-term reliability.

4. Saturation Voltage (V<sub>CE(sat)</sub>)

When a transistor operates in the saturation region (fully turned on), V<sub>CE(sat)</sub> is the voltage drop between the collector and emitter. Lower values indicate better efficiency, as less power is wasted as heat. YFW’s 2SC2383-Y exhibits a V<sub>CE(sat)</sub> of 1.5 V at 500 mA , ideal for low-loss switching in power electronics.


In battery-powered devices, minimizing V<sub>CE(sat)</sub> is critical for extending runtime. YFW’s low-saturation transistors optimize energy efficiency in applications like DC-DC converters and motor control.

5. Cutoff Frequency (f<sub>T</sub>)

The cutoff frequency (f<sub>T</sub>) is the frequency at which the current gain drops to unity, marking the upper limit for effective signal amplification. YFW’s high-frequency transistors, designed for RF applications , feature f<sub>T</sub> values exceeding 100 MHz, ensuring stable performance in wireless communication systems.


For applications like radio receivers or high-speed data transmission, selecting a transistor with an appropriate f<sub>T</sub> is vital. YFW’s RF transistors, such as those in SOT-23 packages, balance high frequency response with compact size.

6. Reverse Breakdown Voltages (V<sub>CBO</sub>, V<sub>EBO</sub>)

These parameters define the maximum reverse voltages the collector-base (V<sub>CBO</sub>) and emitter-base (V<sub>EBO</sub>) junctions can withstand. Exceeding these values may cause avalanche breakdown. YFW’s transistors are rigorously tested to ensure compliance with JEDEC standards , providing a safety margin for overvoltage protection.

7. Leakage Current (I<sub>CBO</sub>, I<sub>CEO</sub>)

Leakage currents (I<sub>CBO</sub> and I<sub>CEO</sub>) are the small currents that flow when the transistor is in cutoff mode. Lower leakage is desirable for low-power applications. YFW’s 2SA1013-Y specifies a collector cutoff current (I<sub>CBO</sub>) of 1 μA , ensuring minimal power loss in standby circuits.

8. Thermal Resistance (R<sub>θJA</sub>)

Thermal resistance measures the efficiency of heat dissipation from the junction to the ambient environment. YFW’s surface-mount transistors, such as those in SOT-89 packages , feature low thermal resistance, enabling efficient heat management in compact designs.

Practical Considerations for Parameter Selection

  • Application-Specific Requirements: For audio amplifiers, prioritize high hFE and low V<sub>CE(sat)</sub>. For motor control, focus on V<sub>CEO</sub> and I<sub>C</sub>.

  • Environmental Factors: High-temperature environments require transistors with robust thermal specifications (e.g., T<sub>J(max)</sub>).

  • Manufacturer Reliability: YFW’s commitment to quality and JEDEC compliance ensures consistent performance across batches.

Conclusion

Transistor parameters are the building blocks of electronic design, dictating performance, efficiency, and reliability. YFW’s portfolio of transistors, including the 2SA1013-Y and 2SC2383-Y , exemplifies the company’s dedication to delivering components with precise parameter control. By understanding these parameters and leveraging YFW’s technical expertise, engineers can design circuits that meet the demands of modern applications, from consumer electronics to industrial systems.


For detailed specifications and application notes, visit YFW’s official website at www.yfwdiode.com or contact their technical support team
