Analysis of the working principle of dual color light-emitting diodes

Date:2025-07-04 Categories:Product knowledge Hits:695 From:Guangdong Youfeng Microelectronics Co., Ltd


Dual color light-emitting diode is a special type of light-emitting diode that can switch between emitting light in two different colors. Its working principle is basically similar to that of ordinary light-emitting diodes, both of which emit light by injecting an external voltage to generate charge carriers in the semiconductor material. The following is a brief analysis of the working principle of dual color light-emitting diodes:

1. Semiconductor structure: Dual color light-emitting diodes typically consist of two light-emitting regions (possibly LED chips of different colors) and a shared cathode (or anode). Each luminescent region contains different luminescent materials, corresponding to different luminescent colors.

2. PN junction: Bicolor light-emitting diodes also include a PN junction, which forms an internal electric field at the PN junction when a voltage is applied. When a certain degree of voltage is applied, an internal electric field is formed, causing electrons to flow from the N region to the P region, while holes flow from the P region to the N region, resulting in recombination near the PN junction and producing photons to emit light. Due to its unique structure, dual color light-emitting diodes can emit light of different colors by passing current through different light-emitting regions.

3. Luminescence principle: Different colored light-emitting diodes use different luminescent materials, typically red and green LED chips. Red LEDs typically use semiconductor materials such as gallium arsenide (GaAs), while green LEDs typically use materials such as aluminum gallium phosphorus (AlGaP). These different semiconductor materials have different energy gaps, and when carriers recombine, they release photons of different wavelengths, resulting in different colored luminescence effects.

4. Control principle: The color switching of dual color light-emitting diodes is achieved by controlling the polarity and magnitude of the voltage. For example, when a positive voltage is applied to a red LED and a negative voltage is applied to a green LED, red light will be emitted; When the voltage is reversed, green light will be emitted. By controlling the applied voltage signal, switching between two colors can be achieved.

Overall, dual color light-emitting diodes achieve different colors of light emission by controlling different light-emitting regions. Their working principle is similar to that of ordinary light-emitting diodes, but their structure and control methods are different, allowing for more diverse lighting effects.
