A transistor is a common electronic component whose main function is to amplify or control current. A transistor consists of three regions, namely the emitter region, the base region, and the collector region. Structurally, the central region of a transistor is the base region, with the emitter and collector regions on either side. The parameter indicators of a transistor include gain, maximum dissipated power, maximum voltage, maximum current, etc. The following will provide a detailed introduction to the parameter indicators and structural principles of the transistor.
1、 The structural principle of a transistor
A transistor is a 74HC595D semiconductor device, which means its conductivity is between that of a conductor and an insulator. A transistor consists of two PN junctions, one of which is the emitter junction, the other is the collector junction, and the middle region is the base region. When the transistor is in normal operation, the forward bias voltage between the emitter junction and the base region causes a small number of charge carriers in the base region to be injected into the emitter junction. These charge carriers enter the collector region after passing through the emitter junction, thereby forming a collector current. Therefore, the main function of a transistor is to amplify or control current.
2、 Parameter indicators of transistor
Gain (hFE)
The gain of a transistor (hFE) refers to the ratio of the collector current to the base current, that is, the ratio of the output current to the input current. The higher the gain, the greater the ratio of output current to input current, and the better the amplification effect. The gain of a transistor is generally between tens to thousands, and the gain values of different types of transistors also vary.
Maximum dissipated power (PD)
The maximum dissipated power refers to the maximum power that a transistor can withstand under long-term operation, usually expressed in watts (W). If the maximum dissipated power is exceeded, it may cause the transistor to burn or even be damaged. Therefore, when choosing a transistor, attention should be paid to its maximum dissipated power.
Maximum Voltage (VCEO)
The maximum voltage refers to the maximum voltage that a transistor can withstand during operation, usually expressed in units of volts (V). If the maximum voltage is exceeded, it may cause breakdown or even damage to the transistor. Therefore, when choosing a transistor, attention should be paid to its maximum voltage.
Maximum current (IC)
The maximum current refers to the maximum current that a transistor can withstand during operation, generally expressed in units of amperes (A). If the maximum current is exceeded, it may cause the transistor to overheat or even be damaged. Therefore, when choosing a transistor, attention should be paid to its maximum current.
3、 Classification of Transistors
According to the different structures and characteristics of transistors, they can be divided into the following categories:
NPN type transistor
NPN transistor is a type of PNP transistor with two P-type outer regions and one N-type middle region. In an NPN transistor, the base is P-type, the emitter is N-type, and the collector is P-type. When a forward voltage is applied between the base and emitter, a small number of carriers in the emitter region are injected into the base region, and these carriers are absorbed by a large number of carriers in the base region, thereby forming current amplification. Therefore, NPN type transistors are mainly used to amplify current or control current.
PNP type transistor
PNP transistor is a type of PNP transistor with two N-type outer regions and one P-type middle region. In PNP transistors, the base is N-type, the emitter is P-type, and the collector is N-type. When a negative voltage is applied between the base and emitter, a few carriers in the emitter region are injected into the base region, and these carriers are absorbed by a large number of carriers in the base region, thereby forming current amplification. Therefore, PNP type transistors are mainly used for amplifying current or controlling current.
MOSFET
MOSFET is a metal oxide semiconductor field-effect transistor. MOSFETs typically consist of three regions, namely the source region, the drain region, and the gate region. The gate region is generally a combination of a metal layer and an oxide layer. When a voltage is applied to the gate, electrons in the gate region form a channel between the source and drain regions, thereby forming a leakage current. The main characteristics of MOSFETs are high input impedance, low power consumption, fast speed, and low noise, so they are widely used in electronic devices.
4、 Summary
A transistor is a common electronic component whose main function is to amplify or control current. A transistor consists of three regions, namely the emitter region, the base region, and the collector region. The parameter indicators of a transistor include gain, maximum dissipated power, maximum voltage, maximum current, etc. According to their different structures and characteristics, transistors can be divided into NPN type transistors, PNP type transistors, and MOSFETs. In practical applications, the appropriate transistor model should be selected according to the needs to achieve the best circuit effect
